Buy DC Power Meter, DROK 6.5-100V 100A 12V 24V 36V 48V 60V 72V Volt Amp Watt Meter Lcd Display Multimeter Voltage Current Energy Rv Battery Monitor Voltmeter Ammeter Wattmeter Panel With 100a Shunt

DROK DC 8-100V Coulombmeter 100A Parameter Voltage: 8-100V Current: 0.05-100A Capacity: 0.1-99999AH Power: 50KW Voltage Precision: ±1% + 2 digits Current Precision: ±0.5% + 2 digits Measure Speed: 20 Times per Second Display Board Size: 86*53*17mm/3.39*2.08*0.67in Measure Board Size: 56*36*34mm/2.20*1.42*1.34in Function 1.CLR: current clear function. When no-load current is not zero, enter this function, Short press ▲ to clear the no-load current. 2.BAT: set battery total capacity. 3.BPC: set available capacity percentage. 4.LED: set LCD screen backlight brightness. When measure current is lower than the set value, screen will auto turn off. When measure current is higher than the set value, screen will auto turn on. 7.BKC: set the screen display colors, total 2 colors to choose, black-white and colorful. 8.LAG: set the language(English/Chinese). 9.LVP: Low voltage alarm. After turning on LBR, when the remain capacity is lower than 20% or voltage is lower than LVP, the backlight will flashing to alarm. When charging current is higher than STI, the backlight will also flash. 11.ADS: Communication Address. 12.PAI: the value of current clear. After no-load current clear, the shunt might make current higher than zero, which can set PAI. When current is lower than the set value, the current value will zero. 13.OVP: the voltage value of max capacity. LCD Display --- This coulometer is equipped with 2.4 inches LCD high precision color screen. Backlight Alarm --- After turning on LBR function, when the remain capacity is lower than 20% or voltage is lower than LVP; the backlight will flash to alarm. The backlight will also flash when charging current is higher than STI(the current value for turning off screen). APPLICATION --- can be used as battery charge discharge tester meter coulometer for automotive and car battery; as battery capacity monitor for solar panel; as voltage meter, ampere meter, power meter for RV Boat, etc.
