74HC4051 8 Channel Analog Multiplexer Selector Module Multiplexers Distributor Resolver CJMCU-4051

74HC4051 8-Channel-Mux Multiplexer Selector Module Distributor Resolver CJMCU-4051 Development Board Product Features The 74HC4051 is a high speed CMOS device with a 74HC4051 pin compatible low power Schottky TTL (LSTTL) family 74HC4051 that complies with JEDEC standard no.7A. The 74HC4051 is an 8-channel analog multiplexer/demultiplexer with 3 digital selects (S0 to S2), 1 low active enable (E), and 8 independent inputs/outputs (Y0 to Y7) ) and 1 common input / output (Z). When E is low, one of the 8 switches will be selected by S0 to S2 (low resistance state). When E is high, all switches enter the high impedance state, directly ignoring S0 to S2. VCC and GND are the supply pins for the digital control terminals (S0 to S2, E). As a digital multiplexer/demultiplexer, VEE will be connected to On GND (generally grounded). Product Parameters Analog input and output voltage: -5V ~ 5V Interface communication type: digital simulation Module size: 19.2mm*18.6*3.3mm with two M3 mounting holes Package: 1 x 74HC4051 8-Channel-Mux Multiplexer Selector Module
