10Pcs Electronic Vibration Sensor With Metal Ball Martinique

Description:1.SW-520D is a ball type tilting vibration sensing unidirectional trigger switch. It has a single-passing characteristic when shaking, and it is more convenient and safe to assemble. Working Characteristics: When the product tilt to Conductive terminal more than 15℃, is open circuit OFF-state,when trigger end (gold-plated pin end ) below the horizontal gradient greater than 15℃ angle, is closed circuit ON-state. In horizontal position, shaking easy to trigger, while the golden feet up, shaking is not easy to trigger. Specification:Product Name: Vibration SwitchModel Number: SW-520DConduction Time: 20MSMax. Voltage: 12VRated Thermal Current: 20mAInsulation Resistance: 10M ohmMax. Temperature Resisting: 100℃Pin Size: 10mm x 0.6mm(L*D)Body Dimension: 13mm x 5.5mm(L*D) Package Content:10 x Vibration Switch Model Number: SW-520D; Max. Insulation Resistance: 10M ohm; Conduction Time: 10MS; Max.Temperature Resisting: 100℃ 【ADVANTAGE】Made of metal, the electrical characteristics are similar to the switch, but it is not as dangerous as the switch and has environmental problems. 【APPLICATION】This switch is suitable for touching off the small current circuit not suitable for acting as the mains switching.
